MULTI DIMENSION LATERAL PACKER
Artikel Nr.: PTB
PIPE DOKTOR Wide Range Lateral Packers are products that allow point repair on pipelines. These are produced by vulcanizing SBR+NR rubber and high-strength fabrics. between -30°C and +70°C temperature resistant. Its biggest advantage is that it allows more than one pipe repair with a single product, thanks to its wide diameter range.
*Can be produced as a Push Rod compatible head.
*Can be produced as a Push Rod compatible head.
METRIC
| Size Usage Range | Max. Working Pressure | Deflated Plug Dimensions | ||||
| Min. Diameter | Max. Diameter (mm) |
Diameter | Lenght | Total Lenght | ||
| (mm) | (mm) | (bar) / (psi) | (mm) | (mm) | (mm) | |
| PTB257015 | 25 | 70 | 4.0 / 58 | 20 | 1500 | 1660 |
| PTB257025 | 25 | 70 | 4.0 / 58 | 20 | 2500 | 2660 |
| PTB257030 | 25 | 70 | 4.0 / 58 | 20 | 3000 | 3160 |
| PTB257040 | 25 | 70 | 4.0 / 58 | 20 | 4000 | 4160 |
| PTB257050 | 25 | 70 | 4.0 / 58 | 20 | 5000 | 5160 |
| PTB257060 | 25 | 70 | 4.0 / 58 | 20 | 6000 | 6160 |
| PTB5012510 | 50 | 125 | 4.0 / 58 | 40 | 1000 | 1160 |
| PTB5012515 | 50 | 125 | 4.0 / 58 | 40 | 1500 | 1660 |
| PTB5012525 | 50 | 125 | 4.0 / 58 | 40 | 2500 | 2660 |
| PTB5012530 | 50 | 125 | 4.0 / 58 | 40 | 3000 | 3160 |
| PTB5012540 | 50 | 125 | 4.0 / 58 | 40 | 4000 | 4160 |
| PTB5012550 | 50 | 125 | 4.0 / 58 | 40 | 5000 | 5160 |
| PTB5012560 | 50 | 125 | 4.0 / 58 | 40 | 6000 | 6160 |
| PTB8020010 | 80 | 200 | 3.0 / 44 | 60 | 1000 | 1160 |
| PTB8020015 | 80 | 200 | 3.0 / 44 | 60 | 1500 | 1660 |
| PTB8020020 | 80 | 200 | 3.0 / 44 | 60 | 2500 | 2660 |
| PTB8020030 | 80 | 200 | 3.0 / 44 | 60 | 3000 | 3160 |
| PTB8020040 | 80 | 200 | 3.0 / 44 | 60 | 4000 | 4160 |
| PTB8020050 | 80 | 200 | 3.0 / 44 | 60 | 5000 | 5160 |
| PTB8020060 | 80 | 200 | 3.0 / 44 | 60 | 6000 | 6160 |
| PTB20040010 | 200 | 400 | 3.0 / 44 | 158 | 1000 | 1160 |
| PTB20040015 | 200 | 400 | 3.0 / 44 | 158 | 1500 | 1660 |
| PTB20040020 | 200 | 400 | 3.0 / 44 | 158 | 2000 | 2660 |
| PTB20040030 | 200 | 400 | 3.0 / 44 | 158 | 3000 | 3160 |
| PTB25060010 | 250 | 600 | 2.5 / 36 | 220 | 1000 | 1160 |
| PTB25060015 | 250 | 600 | 2.5 / 36 | 220 | 1500 | 1660 |
| PTB25060020 | 250 | 600 | 2.5 / 36 | 220 | 2000 | 2660 |
| PTB25060030 | 250 | 600 | 2.5 / 36 | 220 | 3000 | 3160 |
IMPERIAL
| Product Code | Size Usage Range | Max. Working Pressure | Deflated Plug Dimensions | |||
| Min. Diameter | Max. Diameter | Diameter | Lenght | Total Lenght | ||
| (inch) | (inch) | (bar) / (psi) | (inch) | (inch) | (inch) | |
| PTB257010 | 1" | 2.8" | 4.0 / 58 | 0.7" | 39.3" | 45.6" |
| PTB257015 | 1" | 2.8" | 4.0 / 58 | 0.7" | 59.0" | 65.3" |
| PTB257025 | 1" | 2.8" | 4.0 / 58 | 0.7" | 98.5" | 104.8" |
| PTB257030 | 1" | 2.8" | 4.0 / 58 | 0.7" | 118.1" | 124.4" |
| PTB257040 | 1" | 2.8" | 4.0 / 58 | 0.7" | 157.5" | 163.7" |
| PTB257050 | 1" | 2.8" | 4.0 / 58 | 0.7" | 197.0" | 203.1" |
| PTB257060 | 1" | 2.8" | 4.0 / 58 | 0.7" | 236.2" | 242.5" |
| PTB5012510 | 2" | 5" | 4.0 / 58 | 1.5" | 39.3" | 45.6" |
| PTB5012515 | 2" | 5" | 4.0 / 58 | 1.5" | 59.0" | 65.3" |
| PTB5012525 | 2" | 5" | 4.0 / 58 | 1.5" | 98.5" | 104.8" |
| PTB5012530 | 2" | 5" | 4.0 / 58 | 1.5" | 118.1" | 124.4" |
| PTB5012540 | 2" | 5" | 4.0 / 58 | 1.5" | 157.5" | 163.7" |
| PTB5012550 | 2" | 5" | 4.0 / 58 | 1.5" | 197.0" | 203.1" |
| PTB5012560 | 2" | 5" | 4.0 / 58 | 1.5" | 236.2" | 242.5" |
| PTB8020010 | 3" | 8" | 3.0 / 44 | 2.3" | 39.3" | 45.6" |
| PTB8020015 | 3" | 8" | 3.0 / 44 | 2.3" | 59.0" | 65.3" |
| PTB8020020 | 3" | 8" | 3.0 / 44 | 2.3" | 78.6" | 85.0" |
| PTB8020030 | 3" | 8" | 3.0 / 44 | 2.3" | 118.1" | 124.4" |
| PTB8020040 | 3" | 8" | 3.0 / 44 | 2.3" | 157.5" | 163.7" |
| PTB8020050 | 3" | 8" | 3.0 / 44 | 2.3" | 197.0" | 203.1" |
| PTB8020060 | 3" | 8" | 3.0 / 44 | 2.3" | 236.2" | 242.5" |
| PTB20040010 | 8" | 16" | 3.0 / 44 | 6.2" | 39.3" | 45.6" |
| PTB20040015 | 8" | 16" | 3.0 / 44 | 6.2" | 59.0" | 65.3" |
| PTB20040020 | 8" | 16" | 3.0 / 44 | 6.2" | 78.6" | 104.8" |
| PTB20040030 | 8" | 16" | 3.0 / 44 | 6.2" | 118.1" | 124.4" |
| PTB25060010 | 10" | 24" | 2.5 / 36 | 8.6" | 39.3" | 45.6" |
| PTB25060015 | 10" | 24" | 2.5 / 36 | 8.6" | 59.0" | 65.3" |
| PTB25060020 | 10" | 24" | 2.5 / 36 | 8.6" | 78.6" | 104.8" |
| PTB25060030 | 10" | 24" | 2.5 / 36 | 8.6" | 118.1" | 124.4" |
